Introduction
The low headroom hoist reduces overall height by 20%~40% compared with conventional hoists through parallel arrangement of hoisting motor and drum and optimized trolley height, effectively solving insufficient lifting height in low workshops and old facility renovations. Retaining complete safety protection devices with smooth operation and easy maintenance, it can be paired with single-girder cranes and jib cranes, widely used in machining, warehousing and other space-constrained scenarios.
Application
Automotive industry
Medical industry
Machinery industry
Amusement facilities industry
Clothing industry / Apparel industry
Our Advantage
Overall height is 20%~40% lower than conventional hoists, providing greater effective lifting height under the same workshop conditions without structural modifications.
Integrated design of hoisting mechanism and trolley offers compact structure, low center of gravity and high rigidity, reducing sway during operation and significantly improving lifting stability.
Can be directly mounted on standard I-beam rails and single-girder cranes without additional girder height increase, adapting to existing workshop equipment with low renovation cost and short cycle.
Equipped with normal and slow lifting speeds, normal speed ensures efficient hoisting while slow speed enables precise positioning, balancing efficiency and accuracy for various working conditions.
Modular design facilitates disassembly and inspection; standard upper/lower limit switches, electromagnetic brake and rope guide ensure fast braking response and maximum safety for personnel and cargo.
Specification
| Parameter | 0.5t | 1t | 2t | 3t | 5t | 10t |
| Rated Capacity | 0.5t | 1t | 2t | 3t | 5t | 10t |
| Lifting Height | 6~30 m | 6~30 m | 6~30 m | 6~30 m | 6~30 m | 6~30 m |
| Lifting Speed (single) | 8m/min | 8m/min | 8m/min | 8m/min | 8m/min | 7 m/min |
| Lifting Speed (dual) | 8/0.8 | 8/0.8 | 8/0.8 | 8/0.8 | 8/0.8 | 7/0.7 |
| Traveling Speed | 20 m/min | 20 m/min | 15 m/min | 15 m/min | 10 m/min | 10 m/min |
| Hoisting Motor | 0.8 kW | 1.5kW | 3.0kW | 4.5 kW | 7.5kW | 13 kW |
| Trolley Motor | 0.2kW | 0.2kW | 0.4kW | 0.4kW | 0.8kW | 0.8kW×2 |
| Wire Rope Dia. | Φ7.7 | Φ11 | Φ13 | Φ15 | Φ17.5 | Φ15.5×2 |
