Introduction
The integrated hoist adopts modular integrated design, combining hoisting mechanism and traveling trolley via precision-machined connecting base, with built-in or side-mounted electrical control box, featuring neat appearance and small footprint. Equipped with hard-tooth-surface reducer, high-precision rope guide and electromagnetic brake, it operates smoothly with low noise and accurate positioning. Can be directly mounted on I-beam rails or single-girder cranes without additional debugging, ready to use, serving as an upgraded alternative to traditional split-type hoists.
Application
Automotive industry
Medical industry
Machinery industry
Amusement facilities industry
Clothing industry / Apparel industry
Our Advantage
Hoisting, traveling and electrical systems are integrated into one unit, with overall height reduced by over 25% compared with traditional split types, effectively saving workshop headroom and maximizing lifting space.
Fully assembled and debugged before delivery, on-site installation only requires mounting on rail and power connection, reducing installation time by 60% and significantly lowering construction cost and cycle.
Each functional module is independently designed; motor, reducer and brake can be disassembled and replaced separately without full disassembly, ensuring easy maintenance, universal spare parts and low operating cost.
Hard-tooth-surface helical gear reducer and high-precision machined components deliver high transmission efficiency and low vibration, with operating noise below 60dB, improving working environment for noise-sensitive workshops.
Sheet-metal formed housing with powder coating offers modern appearance; compatible with standard I-beams, KBK rails and various single-girder cranes for wide application scenarios.
Specification
| Parameter | 0.5t | 1t | 2t | 3t | 5t | 10t | 16t | 20t | 32t |
| Rated Capacity | 0.5t | 1t | 2t | 3t | 5t | 10t | 16t | 20t | 32t |
| Lifting Height | 6~30m | 6~30m | 6~30m | 6~30m | 6~30m | 6~24m | 6~18m | 6~18m | 6~12m |
| Lifting Speed (N/S) | 8/0.8 | 8/0.8 | 8/0.8 | 8/0.8 | 8/0.8 | 7/0.7 | 3.5/0.35 | 3.5/0.35 | 2.5/0.25 |
| Traveling Speed | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 15 |
| Hoisting Motor | 0.8kW | 1.5kW | 3.0kW | 4.5kW | 7.5kW | 13kW | 13kW | 18.5kW | 22kW |
| Trolley Motor | 0.2kW | 0.2kW | 0.4kW | 0.4kW | 0.8kW | 0.8kW×2 | 0.8kW×2 | 0.8kW×2 | 1.5kW×2 |
| Wire Rope | Φ7.7 | Φ11 | Φ13 | Φ15 | Φ17.5 | Φ15.5×2 | Φ17.5×2 | Φ20×2 | Φ22×2 |
| Suitable I-Beam | 16#~28a | 16#~28a | 20a~32a | 20a~32a | 25a~45a | 30a~56a | 36a~63c | 40a~63c | 45a~63c |
| Working Class | M3 | M3 | M3 | M3 | M3 | M3 | M3 | M3 | M3 |
